The Carlson RT4 is designed for surveying, stake out, construction layout and GIS mapping and is bundled with Carlson SurvPC – the Windows-based data collection program – with the option of running with the Esri® OEM program for use in the field. Or use in the office with any Carlson office software. Along with the 8GB of RAM and 128GB of storage, you can collect and analyze your data quicker than ever before.
See Available Discounts in Cart
Size: 5.40″W x 8.48″L x 1.36″D (137 x 215 x 35mm)
Weight: 1.5-2 pounds (680–907 g) depending on battery configuration
Lightweight and ergonomic design Durable, chemical- and shock-resistant design
Easy-to-grip, impact-absorbing, overmolded bumpers
IP68 waterproof and dust-proof
Operating temperature: -4 F to 122 F (-20 C to 50 C)
Storage temperature: -22 F to 158 F (-30 C to 70 C)
Shockproof: multiple drops from 4′ (1.2 –1.5 m) onto concrete
Designed for MIL-STD-810G test procedures: Method 500.5 Low Pressure (Altitude); Method 501.5 High Temperature; Method 502.5 Low Temperature; Method 503.5 Temperature Shock; Method 506.5 Rain; Method 507.5 Humidity; Method 510.5 Sand and Dust; Method 512.5 Immersion; Method 514.6 Vibration; Method 516.6 Shock
Active viewing area: 7″ (178 mm)
Resolution: WXGA (1280 x 800)
High-visibility backlit LCD for best-in-class sunlight view-ability
Portrait or landscape orientation with automatic screen rotation
USB3.0x1
3.5 mm audio jack
12 VDC power input jack
Docking port connections (Pwr, USB 2.0, & HDMI)
Loud output speaker for noisy environments
Dual digital microphone input for improved clarity
Optional RS-232 9-Pin D-Sub connector with 5VDC power output
Adjustable LED backlit keys
Four-way directional navpad
Windows/home key
Power key
Enter key
Three user-programmable function keys
OEM configurable/customizable
720p webcam with mic
8MP rear camera with LED illumination
Juniper GeotaggingTM: embed photo with date, time, and GNSS position
Long-range Bluetooth® Smart Ready wireless technology, v5.0 +EDR, Class 1.5, BLE support
Wi-Fi® 802.11 a/b/g/n/ac, 2.4 GHz and 5 GHz
4G LTE, support for GSM or Verizon Networks
2 to 5 meter typical accuracy
uBlox NEO-M8N GNSS receiver and integrated antenna
Integrated real-time SBAS receiver (WAAS, EGNOS, etc.)
72 GNSS tracking channels
Optional: uBlox NEO-M8T w/post-processing capability and external GNSS antenna pass- through connection for sub-meter accuracy
Standard removable battery
AC wall charger with international plug kit
Capacitive small-tip stylus w/tether
Quick Start Guide
Hand strap
Connector port dust cover
Microsoft Windows® 10
Multiple languages supported (English, French, Spanish, Portuguese and German)
Quad-core Intel® PentiumTM N4200 Processor
Intel® HD Graphics
8GB RAM (LPDDR4)
128GB flash storage
User-accessible MicroSDXC card slot
Removable Li-Ion batter, 43.2 Whr
Operates 12-15 hours on one charge
Optimized for strong performance in cold temperatures
Removable battery is easily changed in the field
2-year limited warranty, parts and labor
